پشتیبانی از دوربین های
|
DNS-722-4: Supports all D-Link*
network cameras. Includes
support for auto-discovery, and
up to 1.3 megapixel resolution.
DNS-726-4: Supports knownbrand network cameras*
including D-Link, Axis,
Panasonic, Sony, Mobotix,
Arecano, IQinVision, Cisco and
Acti Specific feature support
depends on software.
|
|
کیفیت ضبط
|
Up to 120fps at D1/240fps at CIF for 8 channels
|
|
ضبط صدا و تصویر
|
Synchronized audio & video recording
|
|
فرمت فشرده سازی
|
(H.264, MPEG-4, M-JPEG (for supported cameras
|
|
تنظیمات ویدیو
|
Resolution, quality, frame rate, enable audio, go to camera
interface
|
|
Remote Live View
|
Supported via IE remote live viewer
Maximum 8 simultaneous channel
|
|
Remote Live View Control
|
Live view, preset/go, patrol, focus, PTZ functions, remote IO
DNS-726-4 only), snapshot, full screen, digital zoom)
|
|
Overwrite Recording
|
Auto recycling when disk
storage is full
|
|
فایل خروجی
|
Export videos to “AVI” or “ASF” file
Export images to “BMP” or “JPG” file
|
|
DDNS
|
D-Link DDNS server support
|
|
بک آپ از راه دور
|
Remote software can backup raw data to redundant storage
Auto backup the Video of previous day to FTP server
|
|
System Status
|
Camera status, System status
Still picture EMAP suppport
|
|
پروتکل های شبکه
|
IPV4, ARP, TCP, UDP, ICMP
DHCP Client
(NTP Client (D-Link
DNS Client
(DDNS Client (D-Link
SMTP Client
HTTP Server
PPPoE
UPnP
IP filtering
|
|
رابط کاربری
|
Internet Explorer v6 or later
NVR Search utility
|
|
استانداردهای سخت افزاری
|
IEEE 802.3/u/z
Auto MDI/MDI-X
SATA I, II
|
|
HDD
|
HDD control & manage via PC
Reformat Disk
RAID 0, 1
JBOD
|
|
Flash ROM
|
32MB
|
|
RAM
|
128MB DDR
|
|
رابط کاربری شبکه
|
(Gigabit Ethernet LAN port (10/100/1000 Mbps
|
|
پورت های I/O
|
RJ45 port x1
DC-in jack x1
USB port for UPS status update
(optional)
|
|
منبع تغذیه
|
DC12V/3A, DC5V/3A
|
|
امنیت
|
Front panel lock
Device lock hole
|
|
مصرف انرژی
|
Max. power consumption: 23.59W
Standby state max. power consumption: 7.26W
|
|
برند
|
D-link
|
