رابط کاربری
|
24 پورت SFP
4 پورت ترکیبی 10/100/1000BASE-T
پورت کنسول RS-232
3 درگاه آزاد برای پورت های Uplink
|
|
Installable Module forStacking
|
Single-Port DEM-410CX or DEM-410X
|
|
No. of Units Per physical Stack
|
12
|
|
Switching Fabric
|
108Gbps
|
|
Packet Forwarding Rate
|
80.36Mpps
|
|
Packet Buffer
|
2MB
|
|
IP v4/v6 Routing Table
|
12K Entries
|
|
MAC Address Table
|
16K Entries
|
|
IP v4 Host Table
|
8K Entries
|
|
IP v6 Routing Table
|
6K Entries
|
|
IP v6 Host Table
|
4K Entries
|
|
Jumbo Frame Size
|
9,216Bytes
|
|
منبع تغذیه
|
100to 120 V AC, 200 to 240 V AC, 50/60 Hz, Internal Power Supply
|
|
Power Consumption
|
75.6W
|
|
Optional Redundant PowerSupply
|
DPS-500
|
|
Max Number of StackingPorts Installable
|
2 CX4 or XFP Ports
|
|
Stacking Speed
|
(20Gbps (Full-Duplex
|
|
Heat Dissipation
|
257.96BTU/Hr
|
|
Dimensions
|
441x 389 x 44 mm
|
|
Stackability
|
<strong>Virtual Stacking Support</strong>
D-Link Single IP Management v1.6
Up to 32 devices per virtual stack
Up to 20G stacking bandwidth
Physical Stacking
Supports Duplex Chain/Ring topology
Up to 40G stacking bandwidth
Up to 12 units per stack
|
|
L2 Features
|
<strong>MAC Address Table: 16K</strong>
<strong> Flow Control</strong>
802.3x Flow Control
HOL Blocking Prevention
<strong>Jumbo Frame up to 9,216 Bytes</strong>
<strong> IGMP snooping</strong>
IGMP v1/v2/v3 Snooping
Supports 1 K groups
Port/Host-based
IGMP Snooping
Fast Leave
<strong> MLD Snooping</strong>
MLD v1 Snooping
Supports 1K groups
Host-based MLD Snooping Fast
Leave
<strong> Spanning Tree</strong>
802.1D STP
802.1w RSTP
802.1s MSTP
Per port / per device BPDU filtering
Root Restriction
<strong> Loopback Detection</strong>
<strong> 802.3ad Link Aggregation</strong>
<strong> Max. 32 groups per device</strong>
8 Gigabit ports or 2 10 Gigabit ports
per group
<strong> Port Mirroring</strong>
One-to-One
Many-to-One
Flow-based Mirroring
RSPAN
<strong> L2 Protocol Tunneling</strong>
<strong> ERPS (Ethernet Ring Protection Switching)</strong>
|
|
VLAN
|
<strong> VLAN Group</strong>
Max. 4K Static VLAN Groups
Max. 255 Dynamic VLAN Groups
<strong>802.1Q Tagged VLAN</strong>
<strong> 802.1v Protocol VLAN</strong>
<strong> GVRP</strong>
<strong>(Double VLAN (Q-in-Q</strong>
Port-based Q-in-Q
Selective Q-in-Q
<strong> MAC-based VLAN</strong>
<strong>VLAN Trunking</strong>
<strong> Super VLAN</strong>
|
|
L3 Features
|
<strong> 256 IP interfaces</strong>
<strong>Loopback interface</strong>
<strong>VRRP</strong>
<strong>IPv6 Tunneling</strong>
Static
ISATAP
GRE
6to4
<strong> IPv6 Ready Phase 1/2</strong>
<strong> Proxy ARP</strong>
<strong> Gratuitous ARP</strong>
|
|
L3 Routing
|
<strong>12K hardware routing entries shared by IPv4/v6</strong>
Max. 12K IPv4 routes
Max. 6K IPv6 routes
<strong> 8K hardware L3 forwarding entries shared by IPv4/v6</strong>
Max. 8K IPv4 entries
Max. 4K IPv6 entries
<strong> 256static routing entries for IPv4, 128 entries for IPv6</strong>
Supports ECMP/WCMP
<strong> Policy-based Routing</strong>
<strong> RIP v1/v2</strong>
<strong>(RIPng (IPv6)</strong>
|
|
Size
|
19nch Rack-Mount Width, 1U Height
|
|
Management
|
Web-based GUI
(Command Line Interface (CLI
Telnet Server
Telnet Client
TFTP Client
ZModem
SNMP v1/v2c/v3
SNMP Trap
System Log
RMON v1
RMON v2
sFlow
LLDP
BootP/DHCP Client
DHCP Auto-Configuration
DHCP Relay
DHCP Relay Option 60; 61 *
DHCP Relay Option 82
DHCP Server
Flash File System
Multiple Images
Multiple Configurations
CPU Monitoring
Debug Command
SNTP
ICMPv6
|
|
Security
|
SSH v1/v2
SSL v1/v2/v3
Port Security up to 16 MAC addresses
per port
<strong>Broadcast/Multicast/Unicast Storm Control</strong>
<strong>Traffic Segmentation</strong>
<strong> IP-MAC-Port Binding</strong>
ARP Packet Inspection
IP Packet Inspection
DHCP Snooping
DHCPv6 and NDP Snooping
Supports up to 500 Address Binding
Entries per device
D-Link Safeguard Engine<strong>
DHCP Server Screening
CPU Interface Filtering
ARP Spoofing Prevention
BPDU Attack Protection</strong>
|
|
محل استفاده
|
Rackmount
|
|
تعداد پورت
|
18 تا 28 پورت
|
|
PoE
|
None PoE
|
|
نوع پورت
|
Copper/SFP Gigabit combo
,
Gigabit Ethernet
,
SFP Gigabit
|
|
نوع پورت آپلینک
|
Copper 10 Gigabit
,
Copper/SFP 10 Gigabit Combo
,
SFP 10 Gigabit
|
|
Weight
|
5.5kg
|
|
MTBF
|
289,946hours
|
|
نوع Routing/Switching
|
Layer 3
|
|
برند
|
D-link
|
