پورت
|
24 پورت گیگابیتی شبکه
|
|
استانداردها و قابلیت های پورت
|
IEEE 802.3, 802.3u, 802.3ab compliant
IEEE 802.3z Gigabit fiber
IEEE 802.3x Flow Control
IEEE 802.3az EEE compliant
Half/Full-duplex operation at 10/100Mbps
Full-duplex operation at 1000Mbps
Auto-Negotiation for each port
Auto MDI/MDIX
|
|
ظرفیت سوییچ
|
48Gbps
|
|
Max. Forwarding Rate
|
35.71Mpps
|
|
جدول MAC Address
|
8K
|
|
Packet Buffer
|
512KBytes
|
|
Flash Memory
|
8MBytes
|
|
Forwarding Method
|
Store and Forward
|
|
منبع تغذیه
|
100to 240 VAC, 50 to 60 Hz
Internal Universal Power Supply
|
|
Max. Power Consumption
|
13.9W
|
|
Standby Power Consumption
|
10.4W
|
|
Heat Dissipation
|
47.6BTU/hr
|
|
Operating Temperature
|
0 تا 40C
|
|
Storage Temperature
|
-10 تا 70C
|
|
Operating Humidity
|
10%to95%
non-condensing
|
|
Storage Humidity
|
5%to95%
non-condensing
|
|
ابعاد
|
280mm*180mm*44mm
|
|
وزن
|
1.63kg
|
|
Certifications
|
FCC Class A, CE Class A, VCCI Class A
|
|
Safety
|
UL/cUL, CE LVD
|
|
MTBF
|
2,406,109Hours
|
|
VLAN
|
Port-based VLAN
802.1Q Tagged VLAN
Surveillance VLAN
Voice VLAN
Management VLAN
Max. 4094 VIDs
Supports 128 static VLAN groups
|
|
ویژگی های لایه 2 ای
|
:Flow Control-
802.3x Flow Control
HOL Blocking Prevention
Jumbo Frames up to 9216 Bytes-
:IGMP Snooping-
IGMPv1/v2 Snooping
Supports 64 Groups
:802.3ad Link Aggregation-
12groups, 8 ports per group
Loopback Detection-
Cable Diagnostics-
LLDP-
: Port Mirroring-
One-to-One
:Statistics-
Tx Ok
Tx Error
Rx Ok
Rx Error
:Spanning Tree Protocol-
802.1D STP
802.1w RSTP
SNTP –
L2 Multicast-
|
|
QoS
|
:802.1p Quality of Service-
4queues per port
Queue Handling-
:Bandwidth Control-
Port Based
Ingress: minimum granularity 8 Kbps
Egress: minimum granularity 8 Kbps
|
|
امنیت
|
Traffic Segmentation-
Broadcast/Multicast/Unknown Unicast Storm Control-
:Static MAC Address-
Max. 64 entries
D-Link Safeguard-
DoS Attack Prevention –
|
|
مدیریت
|
Web-Based GUI-
SmartConsole Utility-
|
|
D-Link Green
|
Link Status-
Cable Length-
(Compliant with Energy Efficient Ethernet (IEEE 802.3az-
RoHS Compliant-
|
|
سایز جدول MAC Address
|
8K
|
|
Forwarding Mode
|
Store and Forward
|
|
ویژگی های لایه 2
|
:Flow Control-
802.3x Flow Control
HOL Blocking Prevention
Jumbo Frames up to 9216 Bytes-
:IGMP Snooping-
IGMPv1/v2 Snooping
Supports 64 Groups
:802.3ad Link Aggregation-
12groups, 8 ports per group
Loopback Detection-
Cable Diagnostics-
LLDP-
: Port Mirroring-
One-to-One
:Statistics-
Tx Ok
Tx Error
Rx Ok
Rx Error
:Spanning Tree Protocol-
802.1D STP
802.1w RSTP
SNTP –
L2 Multicast-
|
|
محل استفاده
|
Rackmount
|
|
تعداد پورت
|
18 تا 28 پورت
|
|
PoE
|
None PoE
|
|
نوع پورت
|
Gigabit Ethernet
|
|
نوع پورت آپلینک
|
N/A
|
|
نوع Routing/Switching
|
Layer 2
|
|
برند
|
D-link
|
