سایز
|
11inch Desktop/Rackmount Size
1U Height
|
|
پورت ها
|
8 پورت PoE گیگابیتی شبکه
2 گیگابیتی SFP
|
|
ویژگی های پورت
|
IEEE 802.3 compliant
IEEE 802.3u compliant
IEEE 802.3ab compliant
IEEE 802.3af/802.3at compliant
( IEEE 802.3bt draft/UPoE (DGS-1100-10MPP/26MPP only
IEEE 802.3x Flow Control supports full-duplex mode
Supports manual/auto MDI/MDIX configuration
Auto-negotiation
Supports half/full-duplex operation
IEEE 802.3az compliant
Up to 6 kV surge protection per port
|
|
ظرفیت سوییچ
|
20Gbps
|
|
Maximum Forwarding Rate
|
14.88Mpps
|
|
جدول MAC Address
|
16K
|
|
Packet Buffer
|
1.5MBytes
|
|
Flash Memory
|
16MBytes
|
|
استاندارد PoE
|
IEEE 802.3af/802.3at
|
|
پورت های PoE
|
Ports 1 to 8
30w max per port
|
|
ظرفیت کل PoE
|
130W
|
|
Power Consumption
|
Standby Mode : 10.4W
Maximum Power Consumption :
(141.4W(PoE on
(11.8W(PoE off
|
|
منبع تغذیه
|
100 to 240 V AC
50to 60 Hz Internal Power Supply
|
|
MTBF
|
291,575hours
|
|
Heat Dissipation
|
570.51BTU/hr
|
|
وزن
|
1.83kg
|
|
ابعاد
|
280mm*180mm*44mm
|
|
EMI
|
FCC/IC, CE, VCCI, BSMI, CCC
|
|
Safety
|
cUL, UL, LVD, CB, CCC, BSMI
|
|
VLAN
|
Port-based VLAN-
802.1Q Tagged VLAN-
Auto Surveillance VLAN-
Voice VLAN-
Management VLAN-
Asymmetric VLAN-
:VLAN Group-
Supports 128 static VLAN groups
Max. 4094 VIDs
|
|
ویژگی های لایه 2 ای
|
:Flow Control-
802.3x Flow Control
HOL Blocking Prevention
Jumbo Frames up to 9216 Bytes-
:IGMP Snooping-
IGMP v1/v2/v3 awareness Snooping
Supports 64 Groups
GMP Snooping Querier
:802.3ad Link Aggregation-
DGS-1100-10MP: Support 5 groups per device and 8 ports per group
: Ethernet Ring Protection Switching-
G.8032 ERPS
Loopback Detection-
Cable Diagnostics-
LLDP-
:Port Mirroring-
One-to-One
Many-to-One
:Statistics-
Tx Ok
Tx Error
Rx Ok
Rx Error
:Spanning Tree Protocol-
802.1D STP
802.1w RSTP
:L2 Multicast-
MLD Snooping
|
|
QoS
|
802.1p Quality of Service-
4queues per port-
Queue Handling-
Strict
(Weighted Round Robin (WRR
:(Port-based Bandwidth Control (Rate Limiting-
Ingress : 8Kbps, Egress : 64Kbps
|
|
امنیت
|
D-Link Safeguard
Traffic Segmentation
Broadcast/Multicast/Unknown Unicast Storm Control
DoS Attack Prevention
SSL
|
|
مدیریت
|
( Web-based GUI (Supports IPv4/IPv6
(Client-based Utility (D-Link Network Assistant Utility
|
|
Green Technology
|
:Power Saving by-
Link Status, LED Shut-Off, Port Shut-Off, System Hibernation
Compliant with IEEE 802.3az Energy Efficient Ethernet
|
|
محل استفاده
|
Rackmount
|
|
تعداد پورت
|
16 پورت و کمتر
|
|
PoE
|
802.11af
,
802.11at
|
|
نوع پورت
|
Gigabit Ethernet
|
|
نوع پورت آپلینک
|
Gigabit Fiber
|
|
برند
|
D-link
|
