مشخصات سخت افزاری
|
1/4megapixel progressive CMOS sensor
16feet IR illumination distance
Minimum illumination: 0 lux with IR LEDs on
Built-in Infrared-Cut Removable (ICR) Filter module
4x digital zoom
Focal length: 2.38 mm
Aperture: F2.4
:Angle of view
H) 78.44o)
V) 47.90o)
D) 85.98o)
Minimum object distance: 17 inches
Exposure time: 1/7.5 to 1/24,000 sec
Built-in microphone
|
|
ویژگی های تصویر
|
Adjustable image size, quality, frame rate and bit rate
Adjustable brightness, saturation, contrast, sharpness
and hue
Configurable motion detection windows
Time stamp and text overlays
|
|
فرمت فشرده سازی ویدیو
|
Simultaneous H.264/MJPEG format compression
JPEG for still images
|
|
وضوح ویدیو
|
1280x 720 at up to 30 fps
800x 600 at up to 30 fps
720x 480 at up to 30 fps
640x 480 at up to 30 fps
320x 240 at up to 30 fps
|
|
صدا
|
AAC
G.711
|
|
رابط کاربری
|
Power LED
WPS Button
Direct Connect Button
Reset Button
microUSB Power Connector
|
|
پروتکل های شبکه
|
IPV4, ARP, TCP, UDP, ICMP
DHCP Client
(NTP Client (D-Link
DNS Client
(DDNS Client (D-Link
SMTP Client
FTP Client
HTTP Server
PPPoE
RTP, RTSP, RTCP
UPnP Port Forwarding
HTTPs for configuration
Bonjour
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP digest encryption
|
|
اتصالات بی سیم
|
802.11ac/n/g/b wireless with WEP/WPA/WPA2 encryption
Operates on 2.4GHz and 5GHz frequency bands
|
|
Event Management
|
Event notification and uploading of snapshots/video clips via e-mail (SMTP) or FTP
Motion detection
Sound level detection
|
|
منبع تغذیه
|
5V DC 1.2 A, 50/60 Hz
|
|
ارتباط بی سیم
|
Wi-Fi
|
|
نوع دوربین
|
Indoor
|
|
PoE
|
Non PoE
|
|
برند
|
D-link
|
