مشخصات سخت افزاری
|
1/2.7Full HD progressive megapixel CMOS sensor
10 meter IR illumination distance
Built-in Infrared-Cut Removable (ICR) Filter module
Minimum illumination: 0.12 lux (day mode), 0 lux (night mode) with
IR LED
Fixed lens, 4 mm F1.5 with 77.4 degree horizontal viewing angle
256 Mbytes SDRAM
128 Mbytes of flash memory
Digital Zoom 16X
|
|
ویژگی های تصویر
|
Configurable image size, quality and bit rate
Time stamp and text overlays
3 configurable motion detection windows
ePTZ function
5 configurable privacy masks
Flip & mirror
Configurable white balance, shutter speed, brightness, saturation,
contrast, sharpness
|
|
فرمت فشرده سازی ویدیو
|
H.264/MPEG4/MJPEG dual format compression simultaneously
JPEG for still image
H.264/MPEG-4 multicast streaming
|
|
رزولوشن ویدیو
|
1920×1080 @ 15 fps, 1280×1024 @ 20 fps, 1280×720 @ 30 fps, 640×480 @ 30 fps, 320×240 @ 30 fps, 176×144 @ 30 fps
|
|
ویژگی های صدا
|
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kpbs to 128 kbps
Supports two-way audio and audio mute
|
|
پروتکل های شبکه
|
IPv4, IPv6, TCP/IP, UDP, ICMP, DHCP Client, NTP Client (D-Link), DNS Client, DDNS Client (D-Link), SMTP Client, FTP Client, HTTP / HTTPS,
Samba Client, PPPoE, UPnP Port Forwarding, RTP / RTSP/ RTCP, IP filtering, 3GPP, LLTD, CoS/QoS, SNMP, IGMP, 802.1x, ONVIF Compliant
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP digest encryption
HTTPS streaming
Remote client access control
|
|
D-ViewCam™ SystemRequirements
|
Operating System: Microsoft Windows 7, Vista, XP
Web Browser: Internet Explorer 6 or higher
Protocol: Standard TCP/IP
|
|
مدیریت
|
Motion detection
Tamper Detection
Supports multiple HTTP, SMTP and FTP servers
Multiple event notification
Multiple recording methods for easy backup
Event notification and upload snapshots/video clips via HTTP, SMTP or FTP
|
|
مدیریت از راه دور
|
Configuration accessible via web browser
Take snapshots/video clips and save to local hard drive or NAS via web browser
|
|
ویژگی های نرم افزار مدیریتی
|
Remote management/control of up to 32 cameras
Viewing of up to 32 cameras on one screen
Supports all management functions provided in web interface
Scheduled motion triggered, or manual recording options
|
|
نرم افزارهای تلفن همراه
|
Handsets with 3GPP player, QuickTime 6.5, Real Player 10.5, Windows 2000/ XP/ Vista or 7
|
|
رابط کاربری
|
DI and DO for external sensor and alarm
( External audio input (MIC in
(External audio/video output (AV out
(TV system switch (NTSC/ PAL
MicroSD card slot
|
|
منبع تغذیه
|
12 V DC 1.25 A, 50/60 Hz, IEEE 802.3af PoE
|
|
نوع
|
DOME
|
|
محل نصب
|
Indoor
|
|
برند
|
D-link
|
