مشخصات سخت افزاری
|
1.4Megapixel progressive CMOS sensor
5meter IR illumination distance
:Minimum illumination
0 lux with IR LEDs on
1lux (color), 0.5 lux (B&W) with IR LEDs off
Built-in Infrared-Cut Removable (ICR) Filter module
Lens: Fixed length 2.38 mm:Angle of view
H) 94.36°)
V) 59.3°)
D) 110.44°)
Built-in microphone and speaker
microSD card slot
|
|
مشخصات تصویر
|
Configurable image size, quality
Time stamp and text overlays
configurable motion detection windows
Pre-event snapshot/recording
|
|
فرمت ویدیو
|
H.264/MJPEG format simultaneous compression
JPEG for still images
|
|
رزولوشن ویدیو
|
(H.264: 1280 x 720 (default
640x 480
320x 240 at frame rates up to 30 fps
(MJPEG: 1280 x 720 (default
640x 480
320x 240 at frame rates up to 30 fps
|
|
Pan/Tilt/Zoom
|
(Pan Range :-170° to +170° (total 340°
(Tilt Range:-20° to +90° (total 110°
|
|
فرمت صدا
|
G.711 μ-law
|
|
رابط کاربری
|
10/100BASE-T Fast Ethernet port
Single-band 1T 1R mode supports a maximum data
rate of 72.2 Mbps (PHY rate) using the 20 MHz band
802.11n/g/b wireless
|
|
پروتکل های شبکه
|
IPV4, ARP, TCP, UDP, ICMP
DHCP Client
(NTP Client (D-Link
DNS Client
(DDNS Client (D-Link
SMTP Client
FTP Client
HTTP Server
PPPoE
UPnP Port Forwarding
LLTD
|
|
امنیت
|
WPS
WPA-PSK, WPA2
HTTP digest encryption
Password authentication
|
|
Event Management
|
Motion detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Sound level detection
|
|
ارتباط بی سیم
|
Wi-Fi
|
|
نوع دوربین
|
Indoor
|
|
PoE
|
Non PoE
|
|
برند
|
D-link
|
