مشخصات سخت افزاری
|
1/3” 2 Megapixel progressive CMOS sensor
20meter IR illumination distance
:Minimum illumination
Color (Day Mode), IR LEDs off: 1.0 lux
B/W (Night Mode), IR LEDs off: 0.5 lux
B/W (Night Mode), IR LEDs on: 0 lux
Built-in Infrared-Cut Removable (ICR) Filter module
10x digital zoom
Minimum object distance 0.5 m
Focal length: 2.8 mm
Aperture: F2.0
:Angle of view
H) 84°)
V) 46°)
D) 97°)
:(Adjustment angle (non-motorized
Vertical: 75°
Horizontal: 360°
Rotation: 360°
|
|
بدنه دوربین
|
IP66 compliant weatherproof housing
|
|
ویژگی های تصویر
|
Configurable image size, quality, frame rate, and bit rate
Time stamp and text overlays
Configurable motion detection windows
Configurable privacy mask zones
Configurable exposure time, brightness, saturation, contrast, contrast, sharpness, digital WDR and 3D filter
|
|
فرمت فشرده سازی ویدیو
|
Simultaneous H.264/MJPEG format compression
H.264 multicast streaming
JPEG for still images
|
|
رزولوشن ویدیو
|
16:9- 1280x 720, 800 x 448, 640 x 360, 480 x 272, 320 x 176 up to 30 fps
4:3 – 960x 720, 800 x 592, 640 x 480, 480 x 352, 320 x 240 up to 30 fps
|
|
رابط کاربری
|
(10/100BASE-TX Ethernet port with PoE (802.3af
Optional 12VDC input jack
|
|
پروتکل های شبکه
|
IPv6
IPv4
ARP
TCP/IP
UDP
ICMP
DHCP client
NTP client (D-Link)
DNS client
DDNS client (D-Link)
SMTP client
FTP client
HTTP / HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP / RTSP/ RTCP
IP filtering
QoS/DSCP
CoS
Multicast
ONVIF compliant
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP digest encryption
|
|
مدیریت
|
Motion detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Supports multiple SMTP and FTP servers
Multiple event notifications
Multiple recording methods for easy backup
|
|
مدیریت از راه دور
|
Take snapshots/video clips and save to local hard drive or NAS via web browser
Configuration interface accessible via web browser
|
|
ویژگی های نرم افزار D-viewCam
|
Remote management/control of up to 32 cameras
Supports all management functions provided in web interface
Viewing of up to 32 cameras on one screen
Scheduled motion triggered, or manual recording options
|
|
وزن
|
370 گرم
|
|
منبع تغذیه
|
(PoE (802.3af
12V DC 1.5 A
|
|
گواهینامه
|
CE
CE LVD
FCC
C-Tick
|
|
نوع
|
DOME
|
|
محل نصب
|
Outdoor
|
|
برند
|
D-link
|
