مشخصات سخت افزاری
|
1/3-3Megapixel progressive CMOS sensor
Built-in Infrared-Cut Removable (ICR) filter module
: Minimum illumination
Color (Day Mode): 0.5 lux
B/W (Night Mode), IR LEDs off: 0.25 lux
B/W (Night Mode), IR LEDs on: 0 lux
IR illumination distance: 10 m
Focal length: 2.8 mm
Minimum object distance 0.2 m
Aperture: F2.0
10x digital zoom
:(Angle of view (16:9
H) 84°)
V) 48°)
:(Adjustment angle (non-motorized
Vertical: 340°
Horizontal: 60°
Rotation: 340°
|
|
ویژگی های تصویر
|
Configurable image size, quality, frame rate, and bit rate
Time stamp and text overlays
Configurable motion detection windows
Configurable privacy mask zones
Configurable shutter speed, brightness, saturation, contrast, sharpness, WDR, and 3D filter
|
|
فرمت فشرده سازی ویدیو
|
Simultaneous H.264/MJPEG format compression
H.264/MJPEG multicast streaming
JPEG for still images
|
|
رزولوشن ویدیو
|
: 16:9
1920x 1080, 1280 x 720, 800 x 448, 640 x 360 up to 30 fps
:4:3
2048x 1536 up to 15 fps
1440x 1080, 1280 x 960, 900 x 720, 800 x 592, 640 x 480 up to 30 fps
|
|
رابط کاربری اکسترنال
|
10/100BASE-TX Fast Ethernet port
Supports 802.3af PoE Class 2
|
|
پروتکل های شبکه
|
• IPv6
• IPv4
• ARP
TCP/IP
UDP
ICMP
DHCP client
(NTP client (D-Link
DNS client
(DDNS client (D-Link
SMTP client
FTP client
HTTP/HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP/RTSP/RTCP
IP filtering
Multicast
CoS
QoS/DSCP
SNMP
ONVIF compliant
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP authentication
|
|
مدیریت از راه دور
|
Take snapshots/video clips and save to local hard drive
Configuration interface accessible via web browser
|
|
D-ViewCam™ System Requirements
|
Operating System: Microsoft Windows 8/7/Vista
Web Browser: Internet Explorer 7 or higher
Protocol: TCP/IP
|
|
D-ViewCam™ Software Functions
|
Remote management/control of up to 32 cameras
Supports all management functions provided in web interface
Viewing of up to 32 cameras on one screen
Scheduled motion triggered, or manual recording options
|
|
منبع تغذیه
|
Input: 100 to 240 V AC, 50/60 Hz
Output: 12 V DC 1.5 A
|
|
نوع
|
DOME
|
|
محل نصب
|
Indoor
|
|
برند
|
D-link
|
