مشخصات سخت افزاری
|
1/3Megapixel progressive CMOS sensor
20meter IR illumination distance
:Minimum illumination
(1.0lux / F2.0 (color
(0.5lux /F2.0 (B/W)
( 0lux / F2.0 (IR-LED on)
Built-in Infrared-Cut Removable (ICR) Filter module
10x digital zoom
Minimum object distance 0.2M
Focal length: 2.8 mm
Aperture: F2.0
:Angle of view
H) 96°)
V) 54°)
D) 108°)
:( Adjustment angle (non-motorized
Vertical: 60°
Horizontal: 350°
|
|
ویژگی های تصویر
|
Configurable image size, quality, frame rate, and bit rate
Time stamp and text overlays
Configurable motion detection windows
3Configurable privacy masks zone
Configurable WDR, white balance, shutter speed, brightness,
saturation, contrast, sharpness
|
|
فرمت فشرده سازی ویدیو
|
H.264/MPEG4/MJPEG dual format compression simultaneously
JPEG for still image
H.264/MPEG-4 multicast streaming
|
|
رزولوشن ویدیو
|
16:9 – 1920x 1080, 1280 x 720, 800 x 450, 640 x 360, 480 x 270, 320 x 176, 176 x 144
4:3 – 2048x 1536, 1600 x 1200, 1024 x 768, 800 x 600, 640 x 480, 480 x 360, 320 x 240, 176 x 144
|
|
ویژگی های صدا
|
G.726
|
|
پروتکل های شبکه
|
IPv4, TCP/IP, UDP, ICMP, DHCP Client, NTP Client (D-Link), DNS Client, DDNS Client (D-Link), SMTP Client, FTP Client, HTTP / HTTPS, Samba Client, PPPoE, UPnP Port Forwarding, RTP / RTSP/ RTCP, IP filtering, 3GPP, IGMP, ONVIF compliant
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP digest encryption
|
|
D-ViewCam™ SystemRequirements
|
Operating System: Microsoft Windows 7, Vista, XP
Web Browser: Internet Explorer 6 or higher
Protocol: Standard TCP/IP
|
|
مدیریت
|
Motion detection
Event notification and upload snapshots/video clips via HTTP, SMTP, or FTP
Supports multiple HTTP, SMTP, and FTP servers
Multiple event notifications
Multiple recording methods for easy backup
|
|
مدیریت از راه دور
|
Configuration accessible via web browser
Take snapshots/video clips and save to local hard drive or NAS via web browser
|
|
ویژگی های نرم افزار مدیریتی
|
Remote management/control of up to 32 cameras
Viewing of up to 32 cameras on one screen
Supports all management functions provided in web interface
Scheduled motion triggered, or manual recording options
|
|
نرم افزارهای تلفن همراه
|
Windows 7/Vista/XP system, Pocket PC, or mobile phone with 3GPP playback support
|
|
رابط کاربری
|
10/100BASE-TX Fast Ethernet port
Supports 802.3af PoE Class 2
|
|
منبع تغذیه
|
Input: 100 to 240 V AC, 50/60 Hz
Output: 12 V DC 1.5 A
|
|
بدنه دوربین
|
IP-66 compliant weatherproof housing
IK10 vandal-proof housing
|
|
نوع
|
DOME
|
|
محل نصب
|
Outdoor
|
|
برند
|
D-link
|
