مشخصات سخت افزاری
|
1/3,3Megapixel progressive CMOS sensor
5meter IR illumination distance
:Minimum illumination
Color (Day Mode), IR LEDs off: 0.1 lux
B/W (Night Mode), IR LEDs off: 0.05 lux
B/W (Night Mode), IR LEDs on: 0 lux
Built-in Infrared-Cut Removable (ICR) Filter module
Fixed length 1.72 mm
Aperture F2.0
:Angle of view
H) 180°)
V) 112°)
D) 180°)
Image de-warping
Minimum object distance: 50 cm
Built-in microphone and speaker
|
|
مشخصات تصویر
|
Configurable image size, quality, frame rate, and bit rate
(Wide Dynamic Range (WDR
3D filtering
Time stamp and text overlays
Configurable motion detection windows
Configurable privacy mask zones
Configurable exposure time, brightness, saturation, contrast, sharpness.
|
|
فرمت ویدیو
|
Simultaneous H.264/MPEG-4/MJPEG multi-format compression
JPEG for still images
|
|
رزولوشن ویدیو
|
1920x 1080, 1280 x 720, 640 x 352, 320 x 176 at up to 30 fps
|
|
فرمت صدا
|
G.711 μ-law
|
|
رابط کاربری
|
802.11ac/n/g/b wireless with WPA/WPA2 encryption
Operates on 2.4 GHz and 5 GHz bands
(Maximum data rate of 433 Mbps (PHY rate
|
|
پروتکل های شبکه
|
IPv6, IPv4, TCP/IP, UDP, ICMP
DHCP client
(NTP client (D-Link
DNS client
(DDNS client (D-Link
SMTP client
FTP client
HTTP / HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP / RTSP / RTCP
IP filtering
QoS / CoS
Multicast
ONVIF compliant
Bonjour
SNMP
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP authentication
|
|
Event Management
|
Motion detection
Event notification and uploading of snapshots/video clips via e-mail or FTP
Sound level detection
Scheduled recording
|
|
منبع تغذیه
|
5V DC, 2 A through external power adapter
|
|
ارتباط بی سیم
|
Wi-Fi
|
|
نوع دوربین
|
Indoor
|
|
PoE
|
Non PoE
|
|
برند
|
D-link
|
