مشخصات سخت افزاری
|
1/4Megapixel progressive CMOS sensor
5meter IR illumination distance
Minimum illumination: 0 lux with IR LED on
Built-in Infrared-Cut Removable (ICR) Filter module
(Built-in PIR sensor (5 meter
Built-in microphone
10x digital zoom
Focal length: 3.45 mm
Aperture: F2.0
Exposure time: 1/7.5 to 1/10,000 sec.
Minimum object distance: 500 mm
:Angle of view
H) 57.8°)
V) 37.8°)
D) 66°)
|
|
قاب دوربین
|
IP65 compliant weatherproof housing
|
|
مشخصات تصویر
|
Configurable image size, quality, frame rate, and bit rate
(Wide Dynamic Range (WDR
3D filtering
Time stamp and text overlays
Configurable motion detection windows
Configurable privacy mask zones
Configurable exposure time, brightness, saturation, contrast, sharpness
|
|
فرمت ویدیو
|
Simultaneous H.264/MPEG-4/MJPEG multi-format compression
JPEG for still images
H.264 multicast streaming
|
|
رزولوشن ویدیو
|
16:9:1280×720, 800×448,640×360, 480×272, 320×176
up to 30 fps recording
4:3:960×720, 800×592, 640×480, 480×352, 320×240 up
to 30 fps recording 1
|
|
فرمت صدا
|
AAC
G.711
|
|
رابط کاربری
|
10/100BASE-TX Fast Ethernet port
802.11n/g/b wireless
MicroSD/SDHC card slot
|
|
پروتکل های شبکه
|
IPv6, IPv4, TCP/IP, UDP, ICMP
DHCP client
(NTP client (D-Link
DNS client
(DDNS client (D-Link
SMTP client
FTP client
HTTP / HTTPS
Samba client
PPPoE
UPnP port forwarding
RTP / RTSP / RTCP
IP filtering
QoS / CoS
Multicast
ONVIF compliant
Bonjour
SNMP
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP authentication
|
|
Event Management
|
Motion detection
Event notification and uploading of snapshots/video
clips via e-mail or FTP
Supports multiple SMTP and FTP servers
Multiple event notifications
Multiple recording methods for easy backup
|
|
منبع تغذیه
|
5V DC, 1.2 A through external power adapter
Power adapter: 100 to 240 V AC, 50/60 Hz
|
|
ارتباط بی سیم
|
Non Wi-Fi
,
Wi-Fi
|
|
نوع دوربین
|
Outdoor
|
|
PoE
|
Non PoE
|
|
برند
|
D-link
|
