مشخصات سخت افزاری
|
1/2.7,2Megapixel progressive CMOS sensor
IR Illumination distance: 5 m
Minimum illumination: 0 lux with IR illumination
Built-in Infrared-Cut Removable (ICR) filter module
Built-in PIR (Passive Infrared) sensor
Built-in microphone and speaker
10x digital zoom
Fixed length: 4.37 mm
Aperture: F2.0
:Angle of view
H) 67.4°)
V) 40.8°)
D) 75°)
|
|
ویژگی های تصویر
|
Configurable image size, quality, frame rate, and bit rate
Time stamp and text overlays
Configurable motion detection windows
3configurable privacy mask zones
Configurable shutter speed, brightness, saturation, contrast, and sharpness
|
|
فرمت فشرده سازی ویدیو
|
Simultaneous H.264/MPEG-4/MJPEG format compression
JPEG for still images
H.264/MPEG-4 multicast streaming
|
|
رزولوشن ویدیو
|
16:9-1920x 1080 (up to 15 fps), 1280 x 720, 800 x 450, 640 x 360, 480 x 270, 320 x 176, 176 x 144 up to 30 fps
4:3-1440x 1080 (up to 15 fps), 1280 x 960, 1024 x 768, 800 x 600, 640 x 480, 320 x 240, 176 x 144 up to 30 fps
|
|
فرمت صدا
|
G.726
|
|
رابط های کاربری
|
(10/100BASE-TX Ethernet port (with PoE for DCS-2210 only
(802.11n wireless (DCS-2230 only
1DI / 1 DO
Micro SD card slot
|
|
پروتکل های شبکه
|
IPv4, TCP/IP, UDP, ICMP, DHCP Client, NTP Client (D-Link), DNS Client, DDNS Client (D-Link), SMTP Client, FTP Client, HTTP / HTTPS,
Samba Client, PPPoE, UPnP Port Forwarding, RTP / RTSP/ RTCP, IP filtering, 3GPP, IGMP, ONVIF Compliant
|
|
امنیت
|
Administrator and user group protection
Password authentication
HTTP and RTSP digest encryption
|
|
Event Management
|
Motion detection
PIR motion detection
Event notification and upload snapshots/video clips via HTTP,
SMTP, or FTP
Supports multiple HTTP, SMTP, and FTP servers
Multiple event notifications
Multiple recording methods for easy backup
|
|
مدیریت از راه دور
|
Configuration accessible via web browser
Take snapshots/video clips and save to local hard drive or NAS via web browser
|
|
پیش نیازهای D-ViewCam™ System
|
Operating System: Microsoft Windows 7/Vista/XP
Web Browser: Internet Explorer 6 or higher
Protocol: Standard TCP/IP
|
|
عملکرد D-ViewCam™ Software
|
Remote management/control of up to 32 cameras
Viewing of up to 32 cameras on one screen
Supports all management functions provided in web interface
Scheduled motion triggered, or manual recording options
|
|
منبع تغذیه
|
(5V DC 1.2 A, 50/60 Hz, PoE (DCS-2210 only
|
|
ارتباط بی سیم
|
Non Wi-Fi
|
|
نوع دوربین
|
Indoor
|
|
PoE
|
PoE Support
|
|
برند
|
D-link
|
